Survey and right of way management
Easement checklists and forms
- LVVWD easement checklist
- LVVWD - exclusive easement form
- LVVWD - non-exclusive easement form
- Big Bend Water District exclusive easement form
- Big Bend Water District non-exclusive easement form
- Coyote Springs permanent easement form
Sample easement documents
- Aliquot easement description exhibit A example
- Aliquot exhibit B example
- Exhibit A & B: Example metes and bounds no plat with vacation
- Exhibit A & B: Example metes and bounds GPS derived basis of bearing
- Exhibit A & B: to be used when preparing a plat or parcel map
- Exhibit A & B: to be used when a plat or parcel map is not prepared
- Strip easement description exhibit A example
- Strip exhibit B example
- Surveyor's metes & bounds legal description & exhibit map checklist
Global positioning system
The Water District's global positioning system (GPS) base station network helps engineers and developers design water systems.
The District's GPS base station network comprises 19 sites, 8 of which are National Oceanic and Atmospheric Administration/National Geodetic Survey Continuously Operating Reference Station sites.
View the maps below for approximate locations of the Water District's base station network:
Through cooperative agreements, several other agencies' sites are included in the District's network, including the Nevada Department of Transportation; City of Las Vegas; Clark County Water Reclamation District; and Lincoln County, Nevada.
Static GPS position information
The Water District stores static GPS files for its base station network sites.
This information is available at a 5-second epoch rate, stored as 1-hour files in a zipped Receiver Information Network Exchange data format, beginning and ending at 0:00 and 24:00 Greenwich Mean Time (GMT) respectively.
The 24-hour roll-over is at GMT and is compatible with Pacific Daylight Saving Time (PDT) or Pacific Standard Time (PST) by subtracting 7 or 8 hours respectively. This equates to local roll-over at 4 p.m. PST or 5 p.m. PDT.
The standard for this file type is: (xxxxyyy0.zip), where xxxx = site name, yyy = julian day and 0 = 24-hour file name.
Real-time kinematic (RTK) data link
The current Water District radio transmission frequencies are as follows:
| NVCA | 465.300 mhz | NVWS | 464.550 mhz |
|---|---|---|---|
| NVBM | 465.375 mhz | NVCO | 469.500 mhz |
| NVTR | 460.375 mhz | NVLA | 460.300 mhz |
| NVLM | 465.100 mhz | NVSV | 460.350 mhz |
| NVSL | 460.100 mhz | NVRM | 464.500 mhz |
The Water District currently provides an RTK data link at the frequencies listed above.
The code format is "RTCM 3.x." The over-the-air measurement record is analog, using PacCrest ADL Advantage radios, modulated to Transparent FTS radio encryption. The current protocol settings are: 8-bit coding, none parity and one stop bit (8-none-1) running at 9600 bits-per-second baud rate.
The Water District also provides an RTK data link via the Internet at IP address 205.159.85.60:9899. For GPS users using NTRIP or TCP/IP connections, the Water District provides the following real-time products:
| RT Product Name | Solution |
|---|---|
| RTCM 18 & 19 (v 2.x) | Single baseline |
| Leica (Leica proprietary) | Single baseline |
| CMR (Trimble proprietary) | Single baseline |
| Automax | Network (Leica) |
| IMax | Network (RTCM 3.xx) |
The above products are available using NTRIP caster, at connection port 9899, with the NTRIP mount point named the same as the site name, i.e. NVBM single baseline at NTRIP mount point nvbm.
Note: To obtain access via the Internet using NTRIP, prospective users must contact the District Surveyor at 702-258-7163 to establish an account with a unique user name and password.
